QUICK LINE Aluminum Female Threaded NPT Connector (Straight Adapter)
SKU: QLMPMAL-en
Straight adapter made of **high-strength aluminum**. Connects aluminum piping to components with a **male thread** (like valves or filters) securely and permanently via a **Female NPT thread**.
| Material | High-strength aluminum |
| Max. pressure | 13 bar (188 psi) |
| System | QUICK LINE Quick-Lock |
Available diameters
| Diameter | Code | Weight |
|---|---|---|
| 20 mm | QLGO90AL020 | 0.124 kg |
| 25 mm | QLGO90AL025 | 0.182 kg |
| 32 mm | QLGO90AL032 | 0.310 kg |
| 40 mm | QLGO90AL040 | 0.468 kg |
| 50 mm | QLGO90AL050 | 0.710 kg |
| 63 mm | QLGO90AL063 | 0.980 kg |
| 80 mm | QLGO90AL080 | 1.520 kg |
| 100 mm | QLGO90AL100 | 2.340 kg |
| 110 mm | QLGO90AL110 | 2.850 kg |
The QUICK LINE Aluminum Female Threaded Connector is ideal for **direct connection to the inlet of valves, filters, or equipment** that use a male thread. Its all-aluminum construction guarantees **maximum durability** and resistance, making it the most robust option for high-flow, high-pressure main lines.
The connection to the aluminum pipe is **fast and airtight** thanks to the Quick-Lock system, while the Female NPT thread ensures **standard industrial compatibility**.
Available Variations (Pipe Diameter x Female NPT Thread)
| Ø PIPE x THREAD | PART NO. | WEIGHT (kg/pc) |
|---|---|---|
| 20 x 1/2" NPT | QLMPMAL020048NPT | 0.044 |
| 20 x 3/4" NPT | QLMPMAL020068NPT | 0.045 |
| 25 x 3/4" NPT | QLMPMAL025068NPT | 0.068 |
| 25 x 1" NPT | QLMPMAL025088NPT | 0.070 |
| 32 x 1 1/4" NPT | QLMPMAL032108NPT | 0.157 |
| 40 x 1 1/2" NPT | QLMPMAL040128NPT | 0.335 |
| 50 x 2" NPT | QLMPMAL050168NPT | 0.468 |
| 63 x 2 1/2" NPT | QLMPMAL063208NPT | 0.582 |
Important Notes
- Verify your pipe network diameter before ordering.
- No-weld installation: Quick-Lock quick-connect system.
- Product images are for illustrative purposes only.
